Flow Rate (Cv): 0.07
Body Material: Aluminum
Quantity: 1 (One) piece
Positions: Three way/Two position
Body Material: Aluminum
Quantity: 1 (One) piece
Positions: Three way/Two position
Port Size: Air Inlet=Air Outlet=1/8"NPT
Exhaust: Single
Working Media: 40 Micron Filtered Air
Motion Pattern: Inner Guide Type
Operating Pressure: 0-140 PSI
Operating Temperature:5ºC to + 50ºC / 41ºF to 122ºF
Allowable Voltage Fluctuations: ±10% of Rated Voltage
Power Consumption: AC: 6.5 VA/ DC: 6W
Insulation and Protection: Class F Class / IP65
Wiring Form: Lead Wire or Connector Type
Highest Action Frequency: 5 Cycles/Second
Shortest Excitation Time: 0.05 Second
This precision product works great with other quality MettleAir accessories.
